Shiokaze Framework
A research-oriented fluid solver for computer graphics
recursive_configurable_module Class Reference

recursive_configurable class that also inherits module. More...

#include <recursive_configurable_module.h>

Inheritance diagram for recursive_configurable_module:
recursive_configurable module configurable credit messageable array_core2 array_core3 camera2_interface camera3_interface cellmesher2_interface cellmesher3_interface environment_interface graphics_interface graphplotter_interface gridutility2_interface gridutility3_interface gridvisualizer2_interface gridvisualizer3_interface image_io_interface loop_splitter macadvection2_interface macadvection3_interface macbackwardflip2_interface macbackwardflip3_interface macflip2_interface macflip3_interface maclevelsetsurfacetracker2_interface maclevelsetsurfacetracker3_interface macproject2_interface macproject3_interface macstats2_interface macstats3_interface macutility2_interface macutility3_interface macvisualizer2_interface macvisualizer3_interface meshexporter3_interface meshlevelset_interface meshutility2_interface meshutility3_interface ordering_core parallel_core particlerasterizer2_interface particlerasterizer3_interface pointgridhash2_interface pointgridhash3_interface polygon3_interface RCMatrix_factory_interface< N, T > RCMatrix_solver_interface< N, T > redistancer2_interface redistancer3_interface rigidworld2_interface rigidworld3_interface runnable sysstats_interface timestepper_interface

Public Member Functions

virtual void recursive_load (configuration &config) override
 Start recursively load configurables. More...

virtual void recursive_configure (configuration &config) override
 Recursively call configure. More...

- Public Member Functions inherited from recursive_configurable
 recursive_configurable ()=default
 Default constructor.

virtual void recursive_initialize (const configurable::environment_map &environment=configurable::environment_map())
 Initialize the program itself and relay the same to its children. Used to get things ready for actual use. More...

virtual bool is_ready () const
 Get if the instance is initialized. More...

virtual void add_child (configurable *child)
 Add a child instance. More...

virtual void add_child (recursive_configurable *child)
 Add a child instance. More...

virtual void remove_child (configurable *child)
 Remove a child instance. More...

virtual void remove_child (recursive_configurable *child)
 Remove a child instance. More...

virtual void setup_now (configuration &config=get_global_configuration()) override
 Run recursive_load - recursive_configure - recursive_initialize processes.

virtual bool not_recursive () override
 Check if this instance is not derived from recursive_configurable. More...

void set_environment (std::string name, const void *value)
 Set the pointer to an environmental value associated with an input name. More...

- Public Member Functions inherited from configurable
virtual void load (configuration &config)
 Load the program. Used to load files and libraries into memory. More...

virtual void configure (configuration &config)
 Configure the program. Used to load and set parameters. More...

- Public Member Functions inherited from module
 module ()
 Default constructor for module.

virtual ~module ()
 Default destructor for module.

virtual std::string get_module_name () const
 Get the module name. More...

- Public Member Functions inherited from credit
 credit ()=default
 Default constructor.

 credit (std::string name, std::string argument_name)
 Constructor for credit. More...

virtual void set_name (std::string name, std::string argument_name="")
 Set name (and perhaps, argument name together) More...

virtual std::string get_name () const
 Get the name.

virtual void set_argument_name (std::string argument_name)
 Set an argument name. More...

virtual std::string get_argument_name () const
 Get an argument name. More...

virtual double get_version () const
 Get version. More...

virtual std::string get_author () const
 Get author's name. More...

virtual std::tuple< int, int, int > get_date () const
 Get currently set date. More...

virtual std::string get_email_address () const
 Get email address. More...

- Public Member Functions inherited from messageable
virtual bool send_message (std::string message, void *ptr=nullptr)
 Send a message. More...

virtual bool const_send_message (std::string message, void *ptr=nullptr) const
 Send a message. More...


Additional Inherited Members

- Public Types inherited from configurable
using environment_map = std::map< std::string, const void * >
 Type for environment_map.

- Static Public Member Functions inherited from configurable
static configurationset_global_configuration (const configuration &config)
 Assign the global settings of the program. More...

static configurationget_global_configuration ()
 Get the global settings of the program. More...

template<class T >
static const T & get_env (const environment_map &environment, std::string key)
 Extract an specified type of pointer from the input environment. More...

- Static Public Member Functions inherited from module
static std::string module_libpath (std::string module_name)
 Get the path to the dynamic library. e.g., "mylib" -> "symlink-public/lib/libshiokaze_mylib.dylib". More...

static modulealloc_module (configuration &config, std::string arg_name, std::string default_module_name, std::string description)
 Automatically reads the parameter "arg_name" to fetch the name for the library, and allocate the library. More...

static modulealloc_module (std::string path)
 Reads the dynamic library of a class module, allocate, and return the pointer to it. More...

static unsigned close_all_handles ()
 Close all the handles that are still unloaded. More...

template<class T >
static std::unique_ptr< T > unique_alloc_module (configuration &config, std::string arg_name, std::string default_module_name, std::string description)
 Allocate the module and cast to the a specified class T. More...

static unsigned count_open_modules ()
 Count all the open modules. More...

- Protected Member Functions inherited from configurable
bool check_set (const environment_map &environment, std::vector< std::string > names)
 Check if the values for a variable keys exist. More...

- Protected Attributes inherited from credit
std::string m_name
 Name of credit.

std::string m_argument_name
 Argument name.


Detailed Description

recursive_configurable class that also inherits module.

Member Function Documentation

◆ recursive_configure()

virtual void recursive_configurable_module::recursive_configure ( configuration config)
inlineoverridevirtual

Recursively call configure.

Parameters
[in]configConfiguration setting.

Reimplemented from recursive_configurable.

◆ recursive_load()

virtual void recursive_configurable_module::recursive_load ( configuration config)
inlineoverridevirtual

Start recursively load configurables.

Parameters
[in]configConfiguration setting.

Reimplemented from recursive_configurable.


The documentation for this class was generated from the following file:
